- Multiple function: Quadruplex
- OS:Embedded Linux
- Video Input :16ch-16
- Video Output :Main 1 Composite,1 VGA | Spot 3(16) Digital(Event Shift), Programmable
- Audio Input/Output :16 - 1(RCA)
- Alarm input/Output(Relay): 16 - 4
- Communication Port : RS-232C, RS-422, 2*Ethernet(1 GIGA), USB 2.0
- Power : 100~240V, Universal Voltage

- Compression: H.264
- Data Size: 0.19~0.3 Mbps/ch @30fps(CIF,Low~D1,Ultra)
- Live Display Resolution: 720*480(NTSC)/720*576(PAL)
- Live Display Speed: Real Time
- Display split mode: 1, 4, 6, 7, 8, 9, 10, 13, 16
- Recording Speed: 480fps 720x480,400fps 720x576|480fps 720x240, 400fps 720x288|480fps 360x240, 400fps 360x288
- MODO DE GRABACIÓN: Continuo, Horario, Movimiento y/o Alarma, Limite de Tiempo
- Recording Mode: Continuous, Alarm, Motion, Schedule,Time Limit,
- Recording Quality: Low, Middle, High, Super, Ultra
- Motion Detection: Sensitivity 20 Sensitivity Levels

- Search Method : SMART Search, Date&Time, Event, Log Search
- Playback of Backup file: Mini Player(Auto copy), AVI
- Playback Speed Multi Level: (Full Frame Reverse PB supported)

- Backup Storage Interface:2 x USB 2.0, 2 xSATA(SATA-II), 2 Giga Lan
- External Backup Device: External HDD, DVD-RW, Flash Memory Stick
- Storage HDD: Upto 4 Internal HDDS(SATA-I) | Upto 10 External HDDS(SATA-II) via e-SATA x 2
- CAPACIDAD MÁXIMA DE HDD: 6Tb
- DATA Archiving: Ethernet, Remote PC, External Recording Devices, FTP

- Network Interface : RJ 45/Ethernet
- Network Line: LAN, WAN, Internet
- Network Transmission Speed: Max.480fps
- Pre-Alarm/Post-Alarm : 0 sec~300 sec/10 sec~300 sec
- Q.o.S: Bandwidth Management Supported
- DDNS support: Unique & Public Method
- Event Routing: Source: Alarm, Motion, Video Loss, System | Power Loss, HDD failure, Fan Lock, Temperature
Action Record, System Buzzer, Alarm Relay Spot, E-mail, PTZ Event,

- Controls : Mouse, IR remote, Front Key, CMS, IE
- Firmware Upgrade: USB
- Dimension: 430(w) x 103(H) x 450(D)
- Weight: 10 Kg without HDD
- Power :Consumption 65W
- Operating Temperature: 0°C~40°C
